The XBTGK5330 from Schneider Electric's Magelis series is a robust HMI panel with a 10.4-inch capacitive touchscreen.

SCHNEIDER ELECTRIC XBTGK5330

Original price was: $5,400.50.Current price is: $4,860.25.

Free shipping on orders over $5000!

  • Check Mark Satisfaction Guaranteed
  • Check Mark No Hassle Refunds
  • Check Mark Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
Category:

Description

Model: XBTGK5330
Main
range of product
Harmony XBTGK.
product or component type
Advanced touchscreen panel with keyboard.
display type
Backlit colour TFT LCD.
display colour
65536 colours.
display resolution
640 x 480 pixels VGA.
display size
10.4 inch.
software type
Configuration software.
software designation
Vijeo Designer.
operating system
Harmony..
processor name
CPU RISC
processor frequency
266 MHz.
memory description
512 kB SRAM back up of data with lithium battery backup
32 MB flash EPROM application memory.
integrated connection type
RJ45 connector COM2 serial link with RS485 interface at <= 187.5 kbit/s, compatible with Siemens MPI (187.5 kbit/s).
male SUB-D 9 connector COM1 serial link with RS232C/RS422/RS485 interface at <= 115.2 kbits/s.
removable screw terminal block connector power supply
RJ45 connector Ethernet TCP/IP.
2USB type A master port (V1.1), compatible with Modicon M340 terminal port communication.
3 removable screw terminal block connectors for digital output
removable screw terminal block connector audio output.
removable screw terminal block connector for digital input.
resistance to electrostatic discharge
4 kV, conforming to IEC 61000-4-2 level 3.
cut-out dimensions
285 (+/- 0.4) x 309 (+/- 0.4) mm.
Complementary
touch-sensitive zone
1024 x 1024.
touch panel
Analogue.
backlight lifespan
50000 hours.
brightness
8 levels via touch panel.
contrast
8 levels via touch panel.
character font
ASCII (European characters).
Chinese (simplified Chinese).
Japanese (ANK, Kanji).
Korean
Taiwanese (traditional Chinese).
[Us] rated supply voltage
24 V DC
supply
External source.
supply voltage limits
19.2…28.8 V
inrush current
30 A
power consumption in W
30 W
number of dynamic function keys (symb)
18 with LED.
number of static function keys
12 with LEDs and labels.
number of SERVICE keys
8
number of alphanumeric keys
12
local signalling
1 LED (green or orange) for normal operation or backlightingthat is faulty.
number of pages
Limited by internal memory capacity.
downloadable protocols
Telemecanique Modicon FIPWAY.
Telemecanique Modicon Modbus Plus.
Telemecanique Modicon Modbus TCP.
Telemecanique Modicon Modbus.
Mitsubishi Melsec third-party protocols.
Omron Sysmac third-party protocols.
Rockwell Automation Allen-Bradley third-party protocols.
Siemens Simatic third-party protocols.
Telemecanique Modicon Uni-TE
realtime clock
Built-in
data storage equipment
1 Compact Flash card >= 1 GB.
use of slot
1 fieldbus communication card (Device Net, Profibus DP).
port Ethernet
10BASE-T/100BASE-TX.
product mounting
Flush mounting.
fixing mode
4 screw clamps.
12 spring clips.
front material
Aluminium alloy.
enclosure material
PPT
marking
CE
width
296 mm
height
332 mm
depth
72.7 mm
Environment
immunity to microbreaks
10 ms
standards
UL 1604.
IEC 61000-6-2.
UL 508.
EN 61131-2.
FCC Class A.
CSA C22.2 No. 14
product certifications
CSA Class 1 Division 2 T5.
UL Class 1 Division 2 T5.
CULus
CSA Class 1 Division 2 T4A.
C-Tick.
UL Class 1 Division 2 T4A.
ambient air temperature for operation
0…50 °C.
ambient air temperature for storage
-20…60 °C.
relative humidity
10…90 % without condensation.
operating altitude
< 2000 m.
IP degree of protection
IP20 (rear panel) conforms to IEC 60529.
IP65 (front panel) conforming to IEC 60529
NEMA degree of protection
NEMA 4X front panel (indoor use).
shock resistance
15 gn for 11 ms, conforming to IEC 60068-2-27.
vibration resistance
1 gn conforming to IEC 60068-2-6 (f = 9…150 Hz).
3.5 mm conforming to IEC 60068-2-6 (f = 5…9 Hz).
resistance to electromagnetic fields
10 V/m, conforming to IEC 61000-4-3.
resistance to fast transients
2 kV, conforming to IEC 61000-4-4 level 3.
Packing Units
Package 1: Weight
7.850 kg.
Package 1: Height
220.000 mm.
Package: 1 width
440.000 mm.
Package 1 Length
530.000 mm.
Contractual warranty
Warranty
18 months

Features and Specifications

  • Display and Touchscreen
    • Display Size: The XBTGK5330 typically features a 10.4-inch TFT LCD color touchscreen display.
    • Resolution: Offers high resolution for clear visualization of data and graphics.
    • Touch Technology: Capacitive touchscreen technology for intuitive and responsive interaction.
  • Communication Interfaces
    • Ethernet: Supports Ethernet communication for network connectivity, enabling integration into Ethernet-based industrial networks.
    • Serial Communication: Includes RS485 ports for connecting to various industrial devices and controllers.
    • USB Ports: Provides USB ports for easy data transfer and device connectivity.
  • Software Compatibility
    • Vijeo Designer: Compatible with Schneider Electric’s Vijeo Designer software, a powerful tool for designing, configuring, and programming HMIs. This software allows users to create customized graphical user interfaces (GUIs) tailored to specific industrial applications.
  • Durability and Design
    • Industrial Grade: Designed to withstand tough industrial environments, including resistance to dust, moisture, and wide temperature variations.
    • Mounting Options: Supports panel mounting for installation in control panels or on machinery.
  • Functionality
    • Multi-Language Support: capable of displaying multiple languages, catering to diverse user and operational requirements.
    • Advanced Graphics: Supports dynamic and interactive graphical displays, including animations, alarms, and trends, to provide real-time process monitoring and control.
    • Integration: It easily integrates with Schneider Electric PLCs and other automation devices, facilitating seamless communication and data exchange.
  • Applications
    • Industrial automation is ideal for monitoring and controlling manufacturing processes, equipment operation, and facility management across various industries.
    • User Interface: Provides an intuitive user interface for operators to interact with machines and systems, enhancing productivity and efficiency.
    • Remote Access: Capable of remote access and monitoring, enabling operators and maintenance personnel to manage processes from different locations.
