Description
Unity Processor Modicon Quantum: 548KB-66MHz 140CPU31110
| range of product |
Modicon Quantum automation platform
|
|
|---|---|---|
| product or component type |
Unity processor
|
| clock frequency |
66 MHz
|
|
|---|---|---|
| number of slots |
16
6 2 4 10 |
|
| number of racks |
2: local rack(s)
|
|
| number of distributed I/O station |
63 station(s), 1 rack(s), and 3 Modbus Plus network(s).
|
|
| number of remote I/O station |
31: 2 S908 remote I/O racks,
0–0 ethernet remote I/O rack(s). |
|
| discrete I/O number |
8000 inputs, 8000 outputs, distributed per network (Modbus Plus),
31744 inputs, 31744 outputs, remote, Unlimited (27 slots max): local. |
|
| analogue I/O number |
Unlimited (27 slots max): local
1984 inputs, 1984 outputs: S908 remote I/O. 500 inputs, 500 outputs, distributed per network, (Modbus Plus). |
|
| application specific I/O |
Counter
Accurate time stamping High-speed interrupt inputs Serial link |
|
| number of optional modules |
2 ( Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
|
|
| maximum number of connections |
1 (USB).
2 ( AS-Interface): distributed, 2 ( Ethernet TCP/IP): local 2 ( Modbus Plus): local 2 ( Modbus): RS232/485 Modbus/ASCII, 2 ( Profibus DP): local, 4 (AS-Interface): remote. |
|
| integrated connection type |
1 Modbus Plus with
2 Modbus with |
|
| checks |
Process control
|
|
| memory description |
Internal RAM: 548 kB
|
|
| switch function |
Slide switch memory port/off
Slide switch communication port : ASCII/RTU/Memory |
|
| application structure |
1 cyclic/periodic master task:
1 periodic fast task, 16-timer interrupt tasks, 64 I/O interrupt tasks, 64 interrupt tasks, There are no auxiliary tasks. |
|
| execution time per instruction |
0.1…0.27 µs floating points
0.1…0.27 µs on fixed-point arithmetic 0.12…0.585 µs Boolean 0.12…0.585 µs on word |
|
| number of instructions per ms |
1.86 Kinst/ms if 100 % Boolean
2.49 Kinst/ms if 65 % Boolean and 35 % numerical |
|
| system overhead |
1 ms: master task
0.2 ms: fast task |
|
| bus current requirement |
1800 mA
|
|
| local signalling |
1 LED green communications are active on the Modbus Plus port (Modbus Plus),
1 LED green communications are active on the Modbus port. 1 LED green CPU has been started and is solving logic (RUN). 1 LED green CPU has passed the power-up diagnostic tests (READY), 1 LED orange write-protected memory (memory port), 1 LED red battery needs replacing or is not present (BAT LOW), 1 LED red communications error on the Modbus Plus port (ERROR A). |
|
| electrical connection |
1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network,
2 female connectors, connector type: SUB-D 9, for connecting to the Modbus bus. |
| product certifications |
CE
UL CSA |
|
|---|---|---|
| standards |
HazLoc
|
| Category |
18150: Quantum QUANTUM CONTROLLERS,HSBY,COMM.
|
|
|---|---|---|
| Discount Schedule |
PC21
|
|
| GTIN |
00785901663386
|
|
| Nbr. of units in pkg. |
1
|
|
| Package weight(Lbs) |
1.7
|
|
| Returnability |
N
|
|
| Country of origin |
FR
|
Modicon Quantum Series Overview
The Modicon Quantum series is a range of programmable logic controllers (PLCs) designed for large-scale automation systems. These PLCs are used in various industries, including manufacturing, energy, water treatment, and infrastructure. Key features of the Quantum series include:
- High Processing Power: Capable of handling complex control tasks with fast processing speeds.
- Scalability: Easily expandable with various I/O and communication modules to meet the needs of large automation systems.
- Reliability: Built to withstand harsh industrial environments, ensuring long-term reliability and stability.
- Flexible Communication: Supports multiple communication protocols for integration with other devices and systems.
