| RANGE OF PRODUCT | Modicon Quantum automation platform. |
|---|---|
| PRODUCT OR COMPONENT TYPE | Dc discrete output module. |
| DISCRETE OUTPUT NUMBER | 32 |
| GROUP OF Chanels | 4 groups of 8 |
|---|---|
| DISCRETE OUTPUT LOGIC | Negative logic (sink) |
| ADDRESSING REQUIREMENT | 2 output words 2 input words. |
| DISCRETE OUTPUT VOLTAGE | 10…30 V DC |
| ABSOLUTE MAXIMUM OUTPUT | 50 V for 1 s decaying pulse. |
| MAXIMUM VOLTAGE DROP | <0.4 V, 0.5 A. |
| MAXIMUM LOAD CURRENT | <= 0.5 A each point <= 16 A per module. <= 4 A each group. |
| SURGE CURRENT | 2.5 A for 1 ms |
| RESPONSE TIME | <= 2 ms at state 0 to state 1. <= 2 ms from state 1 to state 0. 1 ms from state 0 to state 1. 1 ms from state 1 to state 0. |
| SHORT-CIRCUIT PROTECTION | With |
| OUTPUT OVERVOLTAGE PROTECTION | With |
| LOAD INDUCTANCE | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 0.5…4 Hz. |
| MAXIMUM TUNGSTEN LOAD | 2.5 W, 10 V. 3 W 12 V 6 W 24 V |
| FAULT INDICATION | Incorrect output state Loss of field power. Blown fuse. |
| PROTECTION TYPE | Internal output protection by 5 A fuse per group. |
| POWER DISSIPATION | 2.5 W + (0.1 x all points on) + (0.4 x total load current). |
| MARKING | CE |
| LOCAL SIGNALLING | 1 LED (green) for bus communication is present (Active). 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status. |
| BUS CURRENT REQUIREMENT | 500 mA |
| MODULE FORMAT | Standard |
| NET WEIGHT | 0.3 kg |
| PRODUCT CERTIFICATIONS | GOST. FM Class 1 Division 2. RMRS. C-Tick. |
|---|---|
| STANDARDS | UL 508 CSA C22.2 No. 142. |
| RESISTANCE TO Electronic DISCHARGE | 4 kV contact conforming to IEC 801-2 8 kV on air, conforming to IEC 801-2. |
| RESISTANCE TO ELECTROMAGNETIC FIELDS | 10 V/m 80…2000 MHz, conforming to IEC 801-3. |
| AMBIENT AIR TEMPERATURE FOR OPERATION | 0…60 °C |
| AMBIENT AIR TEMPERATURE FOR STORAGE | -40…85 °C |
| RELATIVE HUMIDITY | 95% without condensation. |
| OPERATING ALTITUDE | <= 5000 m |
| UNIT TYPE OF PACKAGE 1 | PCE |
|---|---|
| PACKAGE 1 LENGTH | 31.2 cm |
| NUMBER OF UNITS IN PACKAGE 1 | 1 |
| PACKAGE 2 WIDTH | 30 cm |
| PACKAGE 2 HEIGHT | 30 cm |
| PACKAGE 2 WEIGHT | 3.129 kg |
| PACKAGE 1 WIDTH | 4.5 cm |
| PACKAGE 1 HEIGHT | 16.3 cm |
| PACKAGE 1 WEIGHT | 452 g |
| NUMBER OF UNITS IN PACKAGE 2 | 7 |
| UNIT TYPE OF PACKAGE 2 | S03 |
| PACKAGE 2 LENGTH | 40 cm |
Benefits
- Versatility: Can be used in a wide range of applications, from simple control tasks to complex automation processes.
- Reliability: High reliability due to optical isolation and robust design, ensuring consistent performance even in harsh industrial environments.
- Scalability: Easily integrates into existing systems and can be scaled as needed to accommodate additional output requirements.
- Ease of Use: Status LEDs and straightforward configuration make it user-friendly and easy to maintain.
