Description
| Model: | 1756-A13 |
The Allen-Bradley 1756-A13 is a chassis designed for the ControlLogix series of programmable automation controllers (PACs) by Rockwell Automation. This chassis serves as a modular housing that supports various ControlLogix modules, providing a central framework for building scalable and flexible automation systems. Here are the detailed features and specifications of the 1756-A13:
Key Features:
- Modular Design: Allows for the installation of multiple ControlLogix modules, enabling system customization and scalability.
- 13 Slots: Provides 13 module slots, offering ample capacity for a variety of I/O, communication, and controller modules.
- High-Density Connectivity: Supports high-density module configurations, maximizing space utilization in control panels.
- Durable Construction: Built with robust materials to withstand industrial environments and ensure long-term reliability.
- Efficient Power Distribution: Distributes power efficiently to all installed modules through the backplane, ensuring consistent performance.
Specifications:
- Slots: 13 slots for various ControlLogix modules.
- Power Supply Compatibility: Compatible with a range of ControlLogix power supplies, ensuring flexible power options.
- Backplane Current: Supports backplane current ratings suitable for different module configurations.
- Dimensions: Approximately 8.9 x 18 x 5.7 inches (height x width x depth).
- Operating Temperature: Designed to operate in standard industrial temperature ranges, typically 0°C to 60°C.
- Mounting: Can be mounted in standard 19-inch racks or enclosures, providing flexibility in installation.
Applications:
- Manufacturing Automation: Ideal for housing the modules needed for automating production lines, machinery, and processes.
- Process Control: Suitable for complex control systems in industries such as oil and gas, pharmaceuticals, and chemicals.
- Infrastructure Management: Used in the automation and management of utilities and infrastructure projects.
Installation and Configuration:
- Physical Installation: Easily mounted into control panels or enclosures, providing a secure and organized framework for modules.
- Module Installation: Supports easy insertion and removal of modules, facilitating quick setup and maintenance.
- Power Integration: Designed to work seamlessly with ControlLogix power supplies, ensuring efficient power distribution.
Advantages:
- Scalability: The 13-slot capacity allows for significant system expansion as automation needs grow.
- Reliability: Known for its durable construction and reliable performance in demanding industrial conditions.
- Versatility: Compatible with a wide range of ControlLogix modules, providing a versatile solution for various control needs.
