Weintek's HMIET6500 features a robust analogue resistive touchscreen for precise industrial control in a compact design.

HMIET6500 Single touch Analogue Resistive

Original price was: $1,365.00.Current price is: $1,050.00.

2 in stock

Free shipping on orders over $5000!

  • Check Mark Satisfaction Guaranteed
  • Check Mark No Hassle Refunds
  • Check Mark Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
Category:

Description

Main
Range of product Easy Harmony ET6.
Product or component type Touch panel screen.
Software designation Vijeo Designer Basic.
Operating system VxWorks
Processor name ARM Cortex-A8.
Complementary
display size 10 inch.
display type Color TFT LCD.
display colour 16 million colours.
display resolution 1024 x 600 pixels WSVGA.
Touch panel Single-touch analogue resistive.
brightness 16 levels
character font ASCII.
ASCII (European characters)
Chinese (simplified Chinese).
Japanese (ANK, Kanji).
Katakana
Korean
Taiwanese (traditional Chinese).
[Us] rated supply voltage 24 V DC +/- 20 %
Inrush current 30 A
Local signalling Status LED: green, steady for operating.
Status LED orange, steady for software starting up.
Status LED: red, steady for power supply (ON).
Status LED: off for power supply (OFF).
Power consumption in W 11 W
Number of pages 200 application pages.
Processor frequency 800 MHz.
Port Ethernet 10/100BASE.
Memory description Device memory: 256 MB.
User data memory: 256 MB.
Backup memory: 128 kB.
Integrated connection type 1 COM1 serial link; 1 SUB-D 9-pin male; RS232C (rate: 2400…115200 bps)bottom.
1 COM2 serial link; 1 SUB-D 9-pin male; RS422/RS485 (rate: 2400…115200 bps)bottom.
COM2 serial link (rate: 2400–187500 bps) bottom
1 Ethernetbottom.
1 USB 2.0 type Aback.
1 USB 2.0-type micro-back.
Supply External supply.
Realtime clock Built-in 0…50 °C.
Built-in 10–90% RH.
Downloadable protocols Modbus.
Uni-TE.
Third-party protocols.
Product brand Schneider Electric
Fixing mode By 4 screws, mounting on a 1.5-mm thick panel.
Cut-out dimensions 255 x 185 mm panel cut dimension.
Height 201 mm.
Width 271 mm.
depth 47 mm
Net weight 0.99 kg
Environment
Immunity to microbreaks 5 ms
Enclosure material PC
Front material Plastic
Standards EN 61000-6-4.
EN 61000-6-2.
EN 61131-2..
UL 61010-2-201.
CSA C22.2 No. 61010-1-201.
product certifications CE
UL
EAC (pending).
KC-Mark (pending)..
directives 2014/35/EU: Low Voltage voltage directive.
2014/30/EU: electromagnetic compatibility.
Ambient air temperature for operation 0…50 °C.
Ambient air temperature for storage -20…60 °C.
Relative humidity 10…90 % non-condensing.
Operating altitude 2000 m.
IP degree of protection IP20 (rear panel) conforming to IEC 61131-2.
IP65 (front panel) conforming to IEC 61131-2.
Shock resistance 147 m/s2 for 11 ms (X, Y, and Z directions for 3 times). conforming to EN/IEC 61131-2.
Vibration resistance +/- 3.5 mm (f = 5… 9 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to EN/IEC 61131-2.
9.8 m/s2 (f = 9…150 Hz).
Electromagnetic compatibility Electrical fast transient/burst immunity test: test level: 2 kV (power ports) conforming to IEC 61000-4-4.
Electrical fast transient/burst immunity test: test level: 1 kV (signal ports).
Electrostatic discharge immunity test: test level: 6 kV (contact discharge) conforming to EN/IEC 61000-4-2 level 3.
Electrostatic discharge immunity test: test level: 8 kV (air discharge).
Packing Units
Unit Type of Package 1 PCE.
Number of Units in Package 1 1
Package 1: Height 11.000 cm.
Package 1: Width 25.000 cm.
Package 1 Length 37.000 cm.
Package 1: Weight 1.557 kg.
Unit Type of Package 2 S04.
Number of Units in Package 2 5
Package 2: Height 30.000 cm.
Package 2 Width 40.000 cm.
Package 2 Length 60.000 cm.
Package 2: Weight 8.687 kg.

The HMIET6500 Single Touch Analogue Resistive HMI (Human-Machine Interface) is a specialized touch panel developed by Weintek, designed to facilitate user interaction and control in industrial automation environments. Here’s a detailed exploration of its features, specifications, applications, and benefits:

Overview of HMIET6500 Single Touch Analogue Resistive

The HMIET6500 is part of Weintek’s extensive range of HMIs, known for their reliability, versatility, and user-friendly interfaces. It incorporates analogue resistive touchscreen technology, offering precise touch sensitivity and robust performance in diverse industrial applications.

Features and Specifications

  1. Touchscreen Technology: The HMIET6500 utilizes analogue resistive touchscreen technology, which responds to touch input with a high level of accuracy and reliability. This technology is well-suited for environments where operators wear gloves or where touch precision is critical.
  2. Display: Equipped with a high-resolution TFT LCD display, the HMIET6500 provides clear and vibrant visuals for displaying process data, alarms, trends, and other essential information. The display size and resolution ensure optimal visibility and readability in varying lighting conditions.
  3. Processing Power: Powered by a capable processor, the HMIET6500 supports rapid data processing and screen refresh rates, enabling real-time monitoring and control of industrial processes.
  4. Connectivity Options: Offers versatile connectivity options, including Ethernet, USB ports, and serial communication interfaces (RS232/RS485), facilitating seamless integration with PLCs, SCADA systems, and other industrial devices. This connectivity versatility enhances its utility across different automation setups.
  5. Memory and Storage: Provides adequate memory capacity for storing application data, configurations, and historical information. It supports expandable storage options to accommodate additional software modules or future data requirements.
  6. Durability and Design: Designed to withstand harsh industrial environments, the HMIET6500 features a rugged enclosure with protection against dust, moisture, and mechanical impacts. It meets industry standards for durability and reliability, ensuring consistent operation in demanding conditions.
  7. User Interface Customization: Allows customization of the user interface (UI) with graphical elements, alarms, trends, and other visual aids to enhance operator efficiency and usability. Users can tailor the interface to meet specific operational requirements and preferences.
  8. Security Features: Incorporates security measures such as password protection, user authentication, and data encryption to safeguard sensitive information and prevent unauthorized access or tampering.

Applications

The HMIET6500 Single Touch Analogue Resistive HMI is suitable for a wide range of industrial applications:

  • Manufacturing: Controls and monitors production processes in manufacturing plants, enhancing efficiency and productivity through intuitive touchscreen control.
  • Utilities: Manages and supervises utility infrastructure such as water treatment plants, power distribution networks, and HVAC systems, ensuring reliable operation and regulatory compliance.
  • Transportation: Integrates with transportation systems for monitoring and controlling traffic lights, railway signals, and automated guided vehicles (AGVs), optimizing safety and operational efficiency.
  • Building Automation: Interfaces with building management systems (BMS) to regulate HVAC, lighting, and security systems in commercial and residential buildings, enhancing comfort and energy efficiency.

Benefits

  1. Precision and Reliability: Analogue resistive touchscreen technology ensures accurate touch response and durability, suitable for industrial environments where precision control is essential.
  2. Versatile Connectivity: Offers multiple communication interfaces for seamless integration with various industrial automation devices and protocols, supporting flexible and scalable system configurations.
  3. Enhanced Visibility: High-resolution display provides clear and detailed visualization of process data and alarms, facilitating quick decision-making and troubleshooting.
  4. Robust Performance: Built-in processor and memory support rapid data processing and multitasking, enabling real-time monitoring and control of complex industrial processes.
  5. User-Friendly Interface: Intuitive UI customization allows operators to configure screens according to specific operational needs, improving user experience and operational efficiency.

Conclusion

In conclusion, the HMIET6500 Single Touch Analogue Resistive HMI from Weintek exemplifies a robust solution for industrial automation, combining advanced touchscreen technology with versatile connectivity options and durable design. Its precision, reliability, and user-friendly interface make it an essential tool for enhancing control, monitoring, and efficiency across diverse industrial sectors.

This comprehensive overview underscores the HMIET6500 as a reliable choice within Weintek’s HMI portfolio, designed to meet the demanding requirements of modern industrial automation applications.
