140CPS11100 Modicon Quantum

Original price was: $481.00.Current price is: $370.00.

11 in stock

Category:

Description

Main
range of product Modicon Quantum automation platform
product or component type Power supply module
power supply type Standalone
Complementary
input voltage 120…230 V (100…276 V) AC 47…63 Hz
input current 200 mA at 230 V
400 mA at 115 V
inrush current 10 A 230 V
20 A, 115 V
rated power in VA 50 VA
associated fuse rating 1.5 A, slow-blow
harmonic distortion <= 10 % of fundamental rms value
output voltage 5.1 V DC
power supply output current 3 A standalone
output overvoltage protection Internal
output overload protection Internal
power dissipation 2 + (3 x Iout), where Iout is in A
local signalling 1 LED (green) for power (PWR OK)
marking CE
module format Standard
net weight 0.65 kg
Environment
standards UL 508
CSA C22.2 No. 142
product certifications CUL
FM Class 1 Division 2
resistance to electrostatic discharge 4 kV contact conforming to IEC 801-2
8 kV on air, conforming to IEC 801-2
resistance to electromagnetic fields 10 V/m 80…2000 MHz, conforming to IEC 801-3
ambient air temperature for operation 0…60 °C
ambient air temperature for storage -40…85 °C
relative humidity 95 % without condensation
operating altitude <= 5000 m
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1: Height 16.3 cm
Package 1: Width 4.5 cm
Package 1 Length 31.2 cm
Package 1: Weight 665.0 g
Unit Type of Package 2 S03
Number of Units in Package 2 7
Package 2: Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2: Weight 4.543 kg

The 140CPS11100 is a power supply module from the Modicon Quantum series by Schneider Electric, designed to provide reliable and stable power to the Quantum series programmable logic controllers (PLCs) and their associated modules. This power supply module is a critical component in industrial automation systems, ensuring that all connected devices receive consistent and adequate power to operate efficiently and reliably.

Overview

  • Brand: Schneider Electric
  • Series: Modicon Quantum
  • Model: 140CPS11100
  • Type: Power Supply Module

Specifications

  • Input Voltage Range: 93 to 138 VAC or 170 to 276 VAC
  • Input Frequency: 47 to 63 Hz
  • Output Voltage: 24 VDC
  • Output Current: 11 A
  • Power Rating: 150 W
  • Operating Temperature: 0 to 60 °C (32 to 140 °F)
  • Storage Temperature: -40 to 85°C (-40 to 185°F)
  • Humidity: 5 to 95% non-condensing
  • Module Format: Single slot

Features

  1. Wide Input Voltage Range: The 140CPS11100 can accept a broad range of input voltages, making it versatile for various industrial environments.
  2. Stable Output: Provides a stable 24 VDC output with a current capacity of up to 11 A, ensuring reliable power delivery to connected modules.
  3. High Efficiency: Designed for high efficiency to minimize energy losses and reduce operating costs.
  4. Overload Protection: This includes overload protection to prevent damage to the module and connected devices in the event of an excessive current draw.
  5. LED Indicators: Equipped with LED indicators for easy monitoring of power status and diagnostics.
  6. Robust Design: Built to withstand harsh industrial conditions, including wide temperature ranges and high humidity levels.

Applications

  • Manufacturing: Powers PLCs and modules used in manufacturing processes, ensuring reliable control and automation.
  • Process automation is ideal for industries like oil and gas, chemicals, and pharmaceuticals, where consistent and stable power is crucial for process control.
  • Infrastructure: used in transportation systems, water treatment plants, and energy management systems to provide reliable power to control systems.

Installation and Configuration

  • Slot Compatibility: The 140CPS11100 fits into any Quantum series PLC backplane slot, providing flexibility in system design.
  • Wiring: Requires proper wiring according to the module’s pinout diagram to ensure safe and reliable operation.
  • Configuration: This typically requires minimal configuration, with most settings managed automatically by the PLC system.

Advantages

  1. Reliability: The 140CPS11100 is known for its robust performance in industrial environments, ensuring a continuous and reliable power supply.
  2. Versatility: With a wide input voltage range, it can be used in various regions and applications without the need for additional transformers or converters.
  3. Efficiency: High efficiency reduces energy consumption and operational costs, making it an economical choice for industrial power supply needs.
  4. Safety: Overload protection and built-in diagnostics enhance the safety and reliability of the system.

Maintenance and Troubleshooting

  1. Diagnostics: LED indicators provide quick and easy diagnostics to identify and resolve issues promptly, minimizing downtime.
  2. Durability: Designed to withstand harsh industrial conditions, the module offers long-term reliability and reduces the need for frequent maintenance.
  3. Ease of Replacement: In the event of a failure, the 140CPS11100 can be easily replaced without significant system downtime.

Integration with Modicon Quantum System

  • Seamless Integration: The 140CPS11100 is designed to integrate seamlessly with other Modicon Quantum modules, allowing for a cohesive and efficient automation system.
  • Compatibility: Compatible with a wide range of Quantum series modules, it provides flexible power solutions for diverse automation needs.
  • Communication: The module ensures accurate and timely power delivery, essential for the reliable operation of the Quantum PLC system.

Practical Considerations

  • Environmental Conditions: The 140CPS11100 is designed to operate in a wide range of environmental conditions, including temperature and humidity variations typical in industrial settings.
  • Regulatory Compliance: Complies with various industry standards and regulations, ensuring safe and reliable operation in diverse applications.

Conclusion

The 140CPS11100 Modicon Quantum power supply module is a versatile and high-performance component essential for various industrial automation applications. Its ability to handle a wide range of input voltages, provide stable output, and operate efficiently makes it suitable for applications requiring reliable power delivery. The module’s robust design, ease of use, and integration capabilities ensure reliable performance in demanding industrial environments.

Whether used in manufacturing, process automation, or infrastructure projects, the 140CPS11100 provides the necessary features and reliability to meet the needs of modern automation systems. With its high efficiency, overload protection, and diagnostic capabilities, it helps ensure that processes are powered consistently and safely, contributing to overall system efficiency and productivity.
